Built-in hand blender ESM 50

€0.00*

The cordless built-in hand blender ESM 50 is not only quick and easy to use, but also guarantees the greatest possible freedom while cooking.

With its four different attachments, it offers a variety of preparation options.

For the purchase of a built-in system such as this one, it is best to contact a specialist kitchen retailer in your area.

In case you're unsure which model is well suited for installation in your drawer, please refer to our installation guide.

Product number: 625000

Product information "Built-in hand blender ESM 50"

Built-in hand blender ESM 50

For installation in standard drawers with a cabinet width of at least 30 cm
prerequisite: clear width drawer > 145 mm
Charging station is firmly mounted in the drawer and can be removed toolless
The hand blender is always ready to hand and its battery always charged because of the intelligent charging technology
Cordless for greatest possible free movement when cooking
Three speed settings
Various options for food preparation because of four different attachments

cordless, battery-operated hand blender
charging station is firmly mounted in the drawer, can be removed
toolless for cleaning
LED battery level indicator
four attachments made of stainless steel
- universal cutter: standard attachment to blend most food items
- whipping disk: to whip foods
- stirring disk: to stir thick and creamy foods
- cutting blade: to cut meat as well as fibrous fruits and vegetables
three speed settings
aluminum housing, ergonomic plastic handle
two-finger switch-on safety system
automatic safety shut-off in case of overload or overheating

TÜV-Rheinland/GS, CE
plug-in power supply unit for charging station: input voltage 100-240 volt
battery: 7.2 volt, lithium-ion-battery; 2.1 Ah
Power/wattage: 120 watts
weight: 1.4 kg (incl. charging station), 1.0 kg (hand blender)
height: 77 mm width: 138 mm depth: 420 mm (incl. charging station)
height: 67 mm width: 60 mm length: 420 mm (hand blender)

The built-in devices from ritterwerk are, even if they may not look like it, a more complex matter than just unpacking them, placing them in the counter and using them. There are many things to consider, such as the requirements for the installation, the dimensions and the correct mounting of the device. The sale/distribution of the built-in appliances is therefore exclusively carried out via the kitchen furniture industry or kitchen retailers. The installation of built-in appliances should be carried out by qualified personnel (kitchen manufacturers, carpenters, etc.).

We will show you exactly which built-in food slicer is best suited for the respective planning situation in our installation notes. There, you will also find further information on installation and assembly.

GENERAL SAFETY INSTRUCTIONS

To avoid personal injury or damage to the appliance, please observe the following safety instructions:

The hand blender is to be used for domestic purposes only and must not be used commercially.
Assembly (see page 18 or the QR code on the cover) must be performed by qualified personnel only. ritterwerk will not be held liable for the consequences of improper or incorrect assembly.
Do not start using the hand blender until it has been assembled by a professional.
The power cord must be routed in such a way that it is not pinched and can run directly and without obstruction from the built-in system to the socket to be installed in the floor cabinet.
Route the power cord so that it does not come into contact with hot or sharp-edged objects. Do not bend it or wind it around the appliance. Do not allow the power cord to hang down over the edge of the worktop.
The hand blender’s motor unit (2), the charging station (13) and the plug-in power supply (15) must not come into contact with heat, fire, moisture or dirt.
The blender shaft (3) must not come into contact with heat, fire or dirt.
Only connect the plug-in power supply to a suitable AC power source that complies with the specifications on the type label.
Only use the charging station, plug-in power supply and accessories supplied with the blender. The appliance must only be operated using its original parts and accessories.
If all 4 LEDs are flashing continuously at the same time, this indicates a serious electronic fault. This can represent a safety hazard when changing the attachments or accessories and spare parts and during cleaning. Stop using the appliance immediately and have it inspected at an authorized service location. Never touch the attachments. It is no longer possible to charge the battery in this case.
This appliance must not be used by children. Keep the appliance and its connection cable out of reach of children.
Persons with reduced physical, sensory or intellectual capabilities or lacking in relevant experience and/or knowledge may only use this appliance if they do so under supervision or have been instructed in the safe use of the appliance and understand the potential risks associated with its use.
Do not allow children to play with the appliance.
Do not start using the hand blender until it is positioned inside a flat-bottomed container.
The hand blender must not be immersed in the food being blended above the level on the blender where the blender shaft meets the motor unit.
Never leave the appliance unattended while it is operating.
Never immerse the entire hand blender, charging station and plug-in power supply in water or any other liquid. Never expose the appliance to rain or any other form of moisture. If the appliance falls into water, first unplug the charging station's plug-in power supply from the mains socket before removing any of the appliance’s components from the water. Have the complete appliance inspected at an authorized service location before using it again.
Always ensure that your hands are completely dry before using the appliance. Do not use the appliance if it is wet or damp or while you are standing on a damp surface. Do not use the appliance outdoors.
The hand blender and charging station are not suitable for washing in a dishwasher.
Never touch any of the attachments while operating the hand blender and never insert any objects into the appliance while it is in use.

Risk of injury

Always remove the plug-in power supply from the socket in the event of a charging station malfunction. When doing so, pull on the plug and not on the cable.
To avoid the risk of personal injury, stop using the appliance immediately if any parts are damaged. Have the complete appliance inspected at an authorized service location before using it again.
If the plug-in power supply or the power cord is damaged, it must be replaced by an original plug-in power supply or power cord, which is available from the manufacturer or the manufacturer's national aftersales service.
Never switch the hand blender on when you are cleaning it, connecting or disconnecting its attachments or when replacing parts or accessories. Keep your fingers away from the buttons to prevent the appliance from switching on accidentally. Never touch the blades on the attachments, as these are very sharp.
Food may splash out of the cup during processing. For this reason, allow hot food to cool before processing to avoid scalding.
If using the hand blender in a saucepan, remove the saucepan from the hot plate before processing.
Ensure that the slot on the attachment you are using is sitting squarely and firmly on the drive shaft pin. If attachments are loose or not firmly attached to the pin, they must not be used and must be replaced.

Risk of explosion

Protect the battery from exposure to heat and fire.

Operating instruction

Special features

Made in Germany

The ritter built-in hand blenders ESM 50 also take our longstanding traditions into account as well as our “made in Germany” quality aspirations. The blenders are largely made of high-quality, sturdy metal and are therefore of high quality.

Clever use of storage space

As the charging station is mounted in the drawer, the existing storage space is put to efficient use and the worktop is available at all times. The charging station can also be removed at any time without the need for tools.

No annoying power cord

Since the built-in blender ESM 50 is powered by a lithium-ion battery, it can be used anywhere without the user being tied to a power socket. This guarantees the greatest degree of freedom when cooking. As it is stored with the charging station, it is also charged at all times.

Different speed settings

The built-in hand blender ESM 50 has three different speed levels and always starts at the highest speed level. By pressing the power button, you can switch between the different speed levels.

Four different attachments

When preparing and/or processing food, just one universal attachment isn’t always sufficient. We therefore offer four different attachments for our cordless built-in hand blender. The attachment can therefore be chosen according to the food which is to be mixed.

Two-finger switch-on safety system

The two-finger switch-on safety system ensures absolute safety for the user. An unlock button, which must be pressed simultaneously with the power button, prevents accidental activation.

Blending unit

To be able to process the food optimally, the blender unit of the built-in hand blender ESM 50 has studs that hold the food in place during its processing. The open design of the blending unit prevents clogging from occurring when processing hard food.

Replaceable battery

You can replace the lithium-ion battery of the built-in hand blender quickly and easily in a few simple steps, should a defect occur. In the spirit of sustainability, replacement batteries are available to order in our online shop.
